XGbE-60
↳ SFP+: Ethernet connectivity up to 10 Gb/s
↳ Network addressable
Our most recent camera operates as a native 10 GbE IP device, integrating effortlessly into SSA/SDA network infrastructures. Perfect for multi-camera installations, it ensures reliable performance across complex imaging systems.
The XGbE-60 is a powerful solution for multi-camera installations and complex imaging environments. With a large-format CMOS sensor, state-of-the-art cooling, ultra-low noise, and robust network features, this camera sets a new benchmark for professional imaging systems.
The foundation of the XGbE-60 lies in its native 10 GbE IP connectivity. This system connects directly to Ethernet networks, streamlining installation and configuration. Supporting SFP+ modules, it delivers data transfer rates of up to 10 gigabits per second, ensuring smooth transmission of high-resolution image streams without bottlenecks.
This architecture allows for long-distance connectivity between the camera and host systems, removing traditional cabling limitations. For organizations managing distributed imaging setups, the ability to integrate directly into existing infrastructures translates to lower setup costs, simplified architecture, and improved scalability.
By being network addressable, multiple units can be deployed across complex environments without overwhelming system architecture. Each camera can be individually managed and monitored, allowing operators to scale from a single unit to a large, synchronized array with ease.
At the heart of the XGbE-60 is the Sony IMX455 CMOS sensor, offering an impressive resolution of 9576 × 6388 pixels. With a sensor diagonal of 43.3 mm (full-frame, 36 mm × 24 mm), it captures vast amounts of detail in every frame. This sensor delivers crisp, data-rich images that reveal the finest details.
Despite its advanced capabilities, the XGbE-60 is designed for ease of use. The streamlined configuration process allows operators to quickly deploy and integrate the camera without needing extensive technical expertise. Its LED signaling feature adds another layer of practicality, visually flagging events or alerts that require operator attention—reducing downtime and simplifying system management.
IMAGE SENSOR
Sony IMX455 CMOS (Mono/Color)
RESOLUTION
9576 x 6388
SENSOR DIAGONAL (EFFECTIVE PIXELS)
43.3 mm
(36 mm x 24 mm)
PIXEL SIZE
3.76 μm
FULL WELL CAPACITY
51 000 e-
READ NOISE
1.2 e- (High Gain Mode)
3.6 e- (Low Gain Mode)
DARK CURRENT
0.0002 e-/s/px at -15°C
MOUNT TYPE
M54 x 0.75 mm
ADC
16 bit
BACK FOCUS DISTANCE
17.5 mm ±0.5 mm (9 mm ±0.5 without levelling plate)
READING MODE
Electronic Rolling Shutter
EXPOSURE RANGE
0.001s to 24 hours
FRAME RATE
4 FPS
POWER SUPPLY
12VDC 5A
